Line level Gain

Bluetooth Gain

Bass

Mid

Treble

Bluetooth name Send name Set a custom name for your Amplifier. Will automatically reboot when changed and this page will require reconnection. Maximum 26 characters including any spaces.

Bluetooth PIN Set PIN Setting a custom PIN will force the use of a code for pairing. Will automatically reboot when changed and this page will require reconnection. Default is 0000 and not required. Max 15 digits.

Touch to mute

Allow voltage pin to mute

Mute if pin high (3~12v) Off=mute if pin low

LED on when in standby

KLAB-B1 detected

LED brightness

Standby timeout Set Timer When no device is paired or audio signal detected the amplifer will automatically revert to standby. Adjust the time by entering a two digit number between 01 and 60. Default is 3 minutes. Will automatically reboot when changed and this page will require reconnection.

Firmware version

Received data clear

Log Clear

Reboot to apply any changes. (Bluetooth will disconnect)

Reboot

Reboot and reset ALL settings to factory default values.

Reset!

Use this page to configure K2Audio KSAS enabled Bluetooth amplifers. The browser hardware must support Bluetooth Low Energy (BLE) and the browser used must support Web Serial connection. The recommended browser is Chrome for Windows, Android and MAC devices or Bluefy browser for iOS devices (The Chrome app for iOS does not support web serial). When connected please wait a few seconds for the page to read back the current settings before making any adjustments. Check the log for error messages if you cannot connect.
